Fastec Imaging TS3 Specifications
| Max Resolution | 1280x1024 |
|---|---|
| Pixel Size | 14 um |
| Sensor Size | 17.9 x 14.3 mm |
| Sensor Type | CMOS, 10-bit (selectable 10/8) |
| Bit Depth | 10-bit (8-bit selectable) |
| Throughput | ~670 MP/s |
| Max Frame Rate | 64,000 fps |
| Memory Options | 4 GB, 8 GB |
| Storage | Internal SSD up to 2 TB (optional), SD card slot, USB |
| Interfaces | GigE, HDMI |
| Lens Mount | C-mount, Nikon F-mount (optional) |
| Power | 26 V |
| Weight | ~1.8 kg |
| Dimensions | 228 x 114 x 89 mm (W x H x L) |
| Features | Handheld battery-powered design, 7-inch touchscreen LCD, FasMotion software (PC/Mac) and built-in web interface, Multiple recording modes (FasFire, FasCorder, BROC), Livestreaming capability, ImageBLITZ auto-trigger |
Documents
- datasheet: TS3 Data Sheet.pdf
- image: TS3 Nikon 200mm f4 19in-To-Face.jpg
